C5-1000 Internal Combustion - LPG, Cushion Tire Forklift

Part Number - C5-1000
C5-1000 Internal Combustion - LPG, Cushion Tire Forklift

Price:  Request Quote for Price

Qty
Shipping options vary
  • C5 Series
  • Lift Capacity: 4000, 5000, 6000, 6500lb Models
  • Lift Height: 57” – 294”
  • Collapsed Height: 54” – 119”
  • Crown Industrial 2.4L LPG Engine
  • Industrial Dual Core Radiator
  • Smooth, Solid Cushion Tires
  • 30” or 36” Load Backrest
  • Standard 42” Fork Length
  • Infinitely Adjustable Steering Column
  • Low Fuel Indicator
  • Tow Pin

C5-1000 Internal Combustion - LPG, Cushion Tire Forklift

Back to Top

Specifications

Maximum Lift Height Up to 294 in (Quad Mast)
Maximum Load Capacity Up to 6500 lb
Application Dock Work, Loading / Unloading, Manufacturing / Assembly (Just-in-Time), Putaway / Retrieval / Takedown, Transport
Truck Type Counterbalance
Environment Indoor, Outdoor-Improved Surface
Power Type LPG
Max Load Capacity (lb) 6500
Lift Height Numeric 294
Series C5 1000
Platform Height N/A
Operating Position Rider Sit-Down
Fork Lengths 32 - 72 in
Empty Travel Speed 11 mph
Mast Type Two Stage / Three Stage / Quad Mast
Empty Lift Lower Speed 125 fpm / 91 fpm
Overall Width 42.9 - 47 in

Product Description

Back to Top

The Crown C-5 Series, equipped with the fully adjustable D4 armrest and one of three seat options, combines an ergonomic fit and all-day comfort for the operator. Pair that with Crown’s reliability through a proven support network, and you have a forklift that gets the job done, shift after shift. Ideal for indoor or outdoor use on approved hard surfaces, such as concrete or blacktop, the Crown C5 cushion tire forklift, delivers strength and durability that comes with a rugged powertrain, enhanced operator productivity with an ergonomic compartment including seat and armrest options, and reliability through a proven support network.

  • C5 Series
  • Lift Capacity: 4000, 5000, 6000, 6500lb Models
  • Lift Height: 57” – 294”
  • Collapsed Height: 54” – 119”
  • Crown Industrial 2.4L LPG Engine
  • Industrial Dual Core Radiator
  • Smooth, Solid Cushion Tires
  • 30” or 36” Load Backrest
  • Standard 42” Fork Length
  • Infinitely Adjustable Steering Column
  • Low Fuel Indicator
  • Tow Pin
