CGC35-55-BCS Internal Combustion - LPG, Cushion Tire Forklift, Box Car Special

Part Number - CGC-35-55-BCS
CGC35-55-BCS Internal Combustion - LPG, Cushion Tire Forklift, Box Car Special

Price:  Request Quote for Price

Qty
Shipping options vary
  • CG Series
  • Lift Capacity: 8000lb, 10000lb, & 12000lb Models
  • Lift Height: 108” – 276”
  • Collapsed Height: 81” – 134”
  • Kubota 3.8 Liter 4-Cylinder LPG Engine
  • Oil-Cooled Disc Brakes – (5-year, 10,000 Hr. Warranty)
  • Dual Serpentine Core Radiator Providing Separate Cooling to the Engine & Radiator
  • Suspension Seat with Hip Restraint & High Visibility Seat Belt
  • Wide Spacious Floorboard with Thick Rubber Floormat
  • Switch-Activated Electronic Parking Brake
  • Rear Travel Handle with Horn
  • Low Step Height

CGC35-55-BCS Internal Combustion - LPG, Cushion Tire Forklift, Box Car Special

Back to Top

Specifications

Maximum Lift Height Up to 276 in
Maximum Load Capacity Up to 12000 lb
Application Dock Work, Loading / Unloading, Manufacturing / Assembly (Just-in-Time), Putaway / Retrieval / Takedown, Transport
Truck Type Counterbalance
Environment Indoor, Outdoor-Improved Surface
Power Type LPG
Max Load Capacity (lb) 12000
Lift Height Numeric 276
Series CG 35-55 BCS
Platform Height N/A
Operating Position Rider Sit-Down
Fork Lengths 41 - 94 in
Empty Travel Speed 10.5 mph
Mast Type Two Stage / Three Stage
Empty Lift Lower Speed 126 fpm / 88.6 fpm
Overall Width 50 - 55.9 in

Product Description

Back to Top

Crown’s cushion tire 8,000 - 12,000lb forklifts are powerful in a big way yet can be maneuverable in a small space. The CG 35-55 Box Car Edition forklift offers a compact footprint and enhanced maneuverability to navigate tight or congested spaces. With an array of standard and optional product features designed to excel in a variety of material handling environments and a compact Box Car Model with a smaller footprint, these cushion tire forklifts deliver dependability, application flexibility and enduring value.

  • CG Series
  • Lift Capacity: 8000lb, 10000lb, & 12000lb Models
  • Lift Height: 108” – 276”
  • Collapsed Height: 81” – 134”
  • Kubota 3.8 Liter 4-Cylinder LPG Engine
  • Oil-Cooled Disc Brakes – (5-year, 10,000 Hr. Warranty)
  • Dual Serpentine Core Radiator Providing Separate Cooling to the Engine & Radiator
  • Suspension Seat with Hip Restraint & High Visibility Seat Belt
  • Wide Spacious Floorboard with Thick Rubber Floormat
  • Switch-Activated Electronic Parking Brake
  • Rear Travel Handle with Horn
  • Low Step Height
